All posts with the tag Kinematics

Bild bestehend aus Bestandteilen der Benutzeroberfläche von der ASOM v10 Kinematik-Software zum Fallbeispiel "Pick-and-Place Kinematik"
ASOM v10
Simulation of a wankel engine with ASOM

Example for the simulation of a Wankel engine with ASOM. For a triangular Wankel piston, the ratio between gear and gear ring must be a constant 2:3. This is ensured here by hidden constraints.

Bild bestehend aus Bestandteilen der Benutzeroberfläche von der ASOM v10 Kinematik-Software zum Fallbeispiel "Kinematik eines flächenbündigen Türgriffs"
ASOM v10
Pick-and-place mechanism with ASOM

Example of a generic parallel pick-and-place mechanism in ASOM v10 with two degrees of freedom. The model is set up in such a way that its drive sits on the specified curve and drives the definition point over the curve with a specific speed profile.

Bild bestehend aus Bestandteilen der Benutzeroberfläche von der ASOM v10 Kinematik-Software zum Fallbeispiel ""
ASOM v10
Kinematics of a flush-mounted retractable door handle

Example for the design of a mechanism for a flush-mounted retractable door handle with separate kinematic syntheses for the two partial systems (two syntheses “in series”).

Bild bestehend aus Bestandteilen der Benutzeroberfläche von der ASOM v10 Kinematik-Software zum Fallbeispiel "Kinetostatisches Sensorfeld"
ASOM v10
Kinetostatic sensor field in ASOM v10

In this example of a four-bar linkage, multiple manual force curves are determined in real time. The concept can of course also be applied to any other type of multi-bar linkage. The kinematic analysis can also be extended, e.g. to include the determination of the corresponding bearing forces.

Bild bestehend aus Bestandteilen der Benutzeroberfläche von der ASOM v10 Kinematik-Software zum Fallbeispiel "Reibung an schiefer Ebene"
ASOM v10
Implement joint friction in kinematic models

This example shows how to implement joint friction for revolute joints in kinematic models in ASOM. With the aid of joint friction elements, a pin diameter and a friction coefficient can be managed for each revolute joint.

Bild bestehend aus Bestandteilen der Benutzeroberfläche von der ASOM v10 Kinematik-Software zum Fallbeispiel "Reibung an schiefer Ebene"
ASOM v10
Friction on an inclined plane

This example in the kinematics software ASOM v10 shows how to implement friction for slider/rail contacts in kinematic models, e.g. to realize the friction of a block on an inclined plane.

Bild bestehend aus Bestandteilen der Benutzeroberfläche von der ASOM v10 Kinematik-Software zum Fallbeispiel ""
ASOM v10
Multiple shadow previews using a rolling bridge as an example

This example of a rolling bridge in ASOM v10 demonstrates how variants in the extended motion control and multiple shadow previews can help you better understand a model without having to play back the simulation completely after each modification.

Bild bestehend aus Bestandteilen der Benutzeroberfläche von der ASOM v10 Kinematik-Software zum Fallbeispiel "Abgleiten und Abrollen von kreisförmiger Form auf beliebiger Form"
ASOM v10
Slide and roll a arbitrary shape on an arbitrary shape

These examples show that the kinematics software ASOM v10 also makes it possible to slide and roll arbitrary shapes on arbitrary shapes.

Bild bestehend aus Bestandteilen der Benutzeroberfläche von der ASOM v10 Kinematik-Software zum Fallbeispiel "Abgleiten und Abrollen von kreisförmiger Form auf beliebiger Form"
ASOM v10
Slide and roll a circular shape on an arbitrary shape

These examples show that the kinematics software ASOM v10 also makes it possible to have arbitrary shapes slide or roll on each other.

Bild bestehend aus Bestandteilen der Benutzeroberfläche von der ASOM v10 Kinematik-Software zum Fallbeispiel "Aktiver Fußgängerschutz für eine Motorhaube"
ASOM v10
Back hatch with gas springs with ASOM v10

In this example, the ASOM v10 kinematics software simulates a back hatch with gas spring support that has a hat shelf as an additional feature.

Bild bestehend aus der Benutzeroberfläche von der ASOM Kinematik-Software zum Fallbeispiel ""
ASOM v7
Kinematics of an Umbrella in ASOM v7

In this video the example of a typical umbrella is used to demonstrate how to purposefully create variations of a kinematic system in ASOM v7 in order to find better solutions.

ASOM v7Automotive industry
Rear Spoiler Kinematics with Joint Friction

Basic example for the kinematics of a rear spoiler with masses, forces and bearing friction.

Bild bestehend aus der Benutzeroberfläche von der ASOM Kinematik-Software zum Fallbeispiel ""
ASOM v7Automotive industry
Kinematic for Pedestrian Protection

In this example the basic kinematics of a pedestrian protection (represented in a simplified way) are analyzed. The pedestrian-protection kinematic consists of a four-bar system and an actuator.

ASOM v7Automotive industry
Retractable Door Handle

Example for the design of a kinematic mechanism for a flush-mounted retractable door handle with kinematic synthesis of two kinematic systems (serial connection of two synthesis methods).
